Test Date: 2016-10-31 11:57
Analysis date: 2016-10-31 13:03
Analysis date: 2016-10-31 13:03
M1073 XRayHRQualification
Summary
| Module | Module | M1073 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 322 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.57 | 0.3 | 70.5 | 217.1 | 0 | 0/0 | 0 | 3769 | 329 | 775 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.55 | 0.28 | 71.3 | 215.3 | 0 | 0/0 | 0 | 3798 | 329 | 810 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.47 | 0.32 | 59.0 | 179.6 | 0 | 0/0 | 0 | 3835 | 302 | 448 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.59 | 0.23 | 52.0 | 155.4 | 0 | 0/0 | 0 | 3843 | 308 | 515 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.59 | 0.22 | 46.8 | 141.5 | 0 | 0/0 | 0 | 3846 | 301 | 414 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.61 | 0.32 | 72.1 | 219.9 | 0 | 0/0 | 0 | 3678 | 328 | 847 |
|
Chip 6
|
A
|
1 | 0 | 99.77 | 99.44 | 1.21 | 71.9 | 217.6 | 0 | 0/0 | 0 | 3797 | 326 | 741 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.56 | 0.31 | 77.1 | 230.3 | 0 | 0/0 | 0 | 3774 | 316 | 662 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.57 | 0.34 | 81.4 | 246.2 | 0 | 0/0 | 0 | 3768 | 351 | 1131 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.56 | 0.81 | 70.1 | 216.7 | 0 | 0/0 | 0 | 3638 | 318 | 642 |
|
Chip 10
|
A
|
0 | 0 | 99.79 | 99.50 | 0.4 | 81.4 | 252.4 | 0 | 0/0 | 0 | 3812 | 349 | 1037 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.56 | 0.24 | 57.1 | 172.7 | 0 | 0/0 | 0 | 3807 | 319 | 672 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.57 | 0.23 | 52.0 | 158.9 | 0 | 0/0 | 0 | 3720 | 318 | 627 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.57 | 0.35 | 73.8 | 228.5 | 0 | 0/0 | 0 | 3745 | 340 | 943 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.53 | 0.22 | 59.9 | 182.3 | 0 | 0/0 | 0 | 3586 | 289 | 373 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.58 | 0.26 | 76.9 | 236.0 | 0 | 0/0 | 0 | 3547 | 330 | 858 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 11:57 | |
| TestDuration | Duration | 0:57:5 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 276 | |
| nWarnings | # Warnings | 42 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 12 | |
| message_eventid_count | Event ID mismatch | 14 | |
| message_readback_count | Readback start marker | 28 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
