Test Date: 2016-10-31 16:06
Analysis date: 2016-10-31 17:13
Analysis date: 2016-10-31 17:13
M1084 XRayHRQualification
Summary
| Module | Module | M1084 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.60 | % |
| Noise | Mean Noise | 308 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.59 | 0.33 | 72.7 | 232.6 | 0 | 0/0 | 0 | 3791 | 307 | 530 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.59 | 0.4 | 82.7 | 260.7 | 0 | 0/0 | 0 | 3738 | 369 | 1360 |
|
Chip 2
|
A
|
1 | 0 | 99.81 | 99.54 | 0.37 | 78.7 | 244.7 | 1 | 0/0 | 0 | 3507 | 356 | 1150 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.61 | 0.21 | 48.1 | 147.0 | 0 | 0/0 | 0 | 3817 | 306 | 506 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.62 | 0.24 | 41.8 | 126.8 | 0 | 0/0 | 0 | 3877 | 283 | 263 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.64 | 0.22 | 47.1 | 144.7 | 0 | 0/0 | 0 | 3872 | 275 | 233 |
|
Chip 6
|
A
|
0 | 0 | 99.84 | 99.51 | 0.13 | 45.3 | 140.7 | 0 | 0/0 | 0 | 3798 | 294 | 349 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.59 | 0.22 | 51.3 | 158.2 | 0 | 0/0 | 0 | 3825 | 322 | 669 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.42 | 0.23 | 51.4 | 158.8 | 0 | 0/0 | 0 | 3363 | 322 | 708 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.96 | 0.19 | 43.1 | 132.5 | 0 | 0/0 | 0 | 3890 | 269 | 154 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.50 | 0.24 | 53.3 | 164.1 | 0 | 0/0 | 0 | 3809 | 310 | 530 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.60 | 0.31 | 42.7 | 129.2 | 0 | 0/0 | 0 | 3837 | 287 | 314 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.66 | 0.26 | 45.8 | 139.9 | 0 | 0/0 | 0 | 3580 | 298 | 437 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.63 | 0.21 | 63.1 | 192.6 | 0 | 0/0 | 0 | 3789 | 306 | 478 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.61 | 0.3 | 61.3 | 187.9 | 0 | 0/0 | 0 | 3811 | 292 | 347 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.59 | 0.34 | 76.3 | 238.9 | 0 | 0/0 | 0 | 3790 | 329 | 843 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 16:06 | |
| TestDuration | Duration | 0:58:0 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 31 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
