Test Date: 2016-10-31 17:08
Analysis date: 2016-10-31 18:12
Analysis date: 2016-10-31 18:12
M1085 XRayHRQualification
Summary
| Module | Module | M1085 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 322 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.50 | 0.25 | 62.0 | 192.2 | 0 | 0/0 | 0 | 3781 | 308 | 527 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.56 | 0.3 | 70.7 | 218.2 | 0 | 0/0 | 0 | 3770 | 344 | 1026 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.58 | 0.29 | 61.1 | 186.0 | 0 | 0/0 | 0 | 3813 | 306 | 493 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.57 | 0.29 | 55.4 | 167.5 | 0 | 0/0 | 0 | 3781 | 332 | 775 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.56 | 0.23 | 50.9 | 152.5 | 0 | 0/0 | 0 | 3856 | 282 | 258 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.53 | 0.3 | 86.7 | 264.1 | 0 | 0/0 | 0 | 3723 | 341 | 963 |
|
Chip 6
|
A
|
1 | 0 | 99.84 | 99.58 | 0.28 | 66.9 | 201.7 | 0 | 0/0 | 0 | 3505 | 296 | 383 |
|
Chip 7
|
A
|
1 | 0 | 99.80 | 99.56 | 0.34 | 82.1 | 252.3 | 2 | 0/0 | 0 | 3783 | 329 | 805 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.57 | 0.32 | 93.1 | 291.6 | 0 | 0/0 | 0 | 3801 | 337 | 950 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.58 | 0.37 | 81.1 | 250.1 | 0 | 0/0 | 0 | 3778 | 330 | 865 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.55 | 0.43 | 86.5 | 266.2 | 0 | 0/0 | 0 | 3787 | 339 | 957 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.63 | 0.26 | 56.5 | 171.0 | 0 | 0/0 | 0 | 3810 | 308 | 543 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.58 | 0.34 | 55.2 | 166.2 | 0 | 0/0 | 0 | 3803 | 335 | 873 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.58 | 0.31 | 72.2 | 216.8 | 1 | 0/0 | 0 | 3754 | 334 | 890 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.57 | 0.25 | 63.4 | 193.1 | 0 | 0/0 | 0 | 3836 | 308 | 556 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.59 | 0.26 | 69.2 | 213.3 | 0 | 0/0 | 0 | 3711 | 316 | 667 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 17:08 | |
| TestDuration | Duration | 0:57:3 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 66 | |
| nWarnings | # Warnings | 6 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 4 |
