Test Date: 2016-11-01 12:00
Analysis date: 2016-11-03 16:10
Analysis date: 2016-11-03 16:10
M1093 XRayHRQualification
| Comment | Comment | comment.txt: Bad DC on C0 |
Summary
| Module | Module | M1093 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | C | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.56 | % |
| Noise | Mean Noise | 343 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.65 | 99.67 | 79.14 | 76.2 | 239.9 | 0 | 0/0 | 0 | 3736 | 353 | 1134 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.59 | 0.23 | 73.6 | 228.3 | 0 | 0/0 | 0 | 3727 | 362 | 1273 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.34 | 76.1 | 236.9 | 0 | 0/0 | 0 | 3736 | 380 | 1503 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.57 | 0.32 | 53.9 | 163.2 | 0 | 0/0 | 0 | 3532 | 368 | 1309 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.54 | 0.17 | 41.6 | 127.6 | 0 | 0/0 | 0 | 3873 | 299 | 412 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.53 | 0.31 | 57.4 | 174.6 | 0 | 0/0 | 0 | 3795 | 353 | 1151 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.40 | 0.25 | 46.2 | 141.3 | 0 | 0/0 | 0 | 3802 | 341 | 914 |
|
Chip 7
|
A
|
0 | 0 | 99.76 | 99.54 | 0.36 | 47.7 | 146.0 | 0 | 0/0 | 0 | 3862 | 327 | 708 |
|
Chip 8
|
A
|
0 | 0 | 99.78 | 99.57 | 0.28 | 51.5 | 157.5 | 0 | 0/0 | 0 | 3861 | 341 | 901 |
|
Chip 9
|
A
|
0 | 0 | 99.80 | 99.66 | 0.27 | 50.0 | 152.6 | 0 | 0/0 | 0 | 3856 | 327 | 769 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.63 | 0.31 | 59.5 | 182.1 | 0 | 0/0 | 0 | 3761 | 355 | 1106 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.51 | 0.3 | 44.2 | 134.1 | 0 | 0/0 | 0 | 3807 | 337 | 908 |
|
Chip 12
|
A
|
0 | 0 | 99.78 | 99.43 | 0.27 | 41.9 | 127.9 | 0 | 0/0 | 0 | 3884 | 306 | 471 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.55 | 0.34 | 71.6 | 218.7 | 0 | 0/0 | 0 | 3768 | 356 | 1157 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.58 | 0.36 | 73.5 | 226.3 | 0 | 0/0 | 0 | 3750 | 344 | 1027 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.55 | 0.45 | 77.8 | 242.5 | 0 | 0/0 | 0 | 3788 | 338 | 970 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-01 | |
| TestTime | Test Time | 12:00 | |
| TestDuration | Duration | 0:57:42 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 32820 | |
| nWarnings | # Warnings | 59692 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 32004 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_readback_count | Readback start marker | 19972 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
