Test Date: 2016-11-01 09:05
Analysis date: 2016-11-01 11:11
Analysis date: 2016-11-01 11:11
M1095 XRayHRQualification
Summary
| Module | Module | M1095 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 12/4/0 | |
| PixelDefects | Total Pixel Defects | 282 | |
| BumpBondingDefects | Bump Bonding Defects | 282 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.53 | % |
| Noise | Mean Noise | 369 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
81 | 0 | 99.82 | 99.50 | 0.34 | 201.4 | 84 | 67.9 | 0/0 | 0 | 3676 | 362 | 1202 |
|
Chip 1
|
A
|
10 | 0 | 99.81 | 99.56 | 0.32 | 216.2 | 12 | 71.8 | 0/0 | 0 | 3673 | 371 | 1343 |
|
Chip 2
|
A
|
3 | 0 | 99.82 | 99.56 | 0.29 | 200.0 | 4 | 66.0 | 0/0 | 0 | 3627 | 378 | 1412 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.50 | 0.17 | 131.6 | 0 | 44.0 | 0/0 | 0 | 3803 | 296 | 360 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.62 | 0.25 | 183.5 | 0 | 60.6 | 0/0 | 0 | 3692 | 364 | 1252 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.58 | 0.46 | 265.5 | 0 | 86.8 | 0/0 | 0 | 3589 | 395 | 1717 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.56 | 0.33 | 243.7 | 0 | 81.5 | 0/0 | 0 | 3440 | 378 | 1438 |
|
Chip 7
|
A
|
0 | 0 | 99.79 | 99.50 | 0.46 | 268.1 | 0 | 89.6 | 0/0 | 0 | 3634 | 387 | 1577 |
|
Chip 8
|
A
|
7 | 0 | 99.81 | 99.56 | 0.27 | 276.4 | 8 | 90.0 | 0/0 | 0 | 3742 | 371 | 1367 |
|
Chip 9
|
A
|
1 | 0 | 99.78 | 99.50 | 0.39 | 275.2 | 3 | 91.5 | 0/0 | 0 | 3617 | 411 | 1922 |
|
Chip 10
|
A
|
6 | 0 | 99.77 | 99.44 | 1.07 | 262.2 | 9 | 86.9 | 0/0 | 0 | 3620 | 384 | 1510 |
|
Chip 11
|
B
|
40 | 0 | 99.81 | 99.53 | 0.25 | 169.0 | 42 | 56.0 | 0/0 | 0 | 3726 | 336 | 838 |
|
Chip 12
|
B
|
77 | 0 | 99.82 | 99.52 | 0.29 | 154.6 | 78 | 51.5 | 0/0 | 0 | 3685 | 356 | 1116 |
|
Chip 13
|
A
|
13 | 0 | 99.82 | 99.54 | 0.39 | 203.7 | 16 | 67.1 | 0/0 | 0 | 3692 | 369 | 1297 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.51 | 0.34 | 209.8 | 0 | 68.9 | 0/0 | 0 | 3677 | 377 | 1394 |
|
Chip 15
|
B
|
44 | 0 | 99.80 | 99.46 | 0.43 | 209.2 | 54 | 69.5 | 0/0 | 0 | 3687 | 366 | 1305 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-01 | |
| TestTime | Test Time | 09:05 | |
| TestDuration | Duration | 0:37:11 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 49 | |
| nWarnings | # Warnings | 6 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 4 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
