Test Date: 2016-11-03 15:45
Analysis date: 2016-11-03 16:30
Analysis date: 2016-11-03 16:30
M1101 XRayHRQualification
Summary
| Module | Module | M1101 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.52 | % |
| Noise | Mean Noise | 375 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.54 | 0.43 | 242.6 | 0 | 77.5 | 0/0 | 0 | 3605 | 405 | 1876 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.55 | 0.29 | 234.8 | 0 | 76.8 | 0/0 | 0 | 3646 | 395 | 1717 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.3 | 239.8 | 0 | 77.9 | 0/0 | 0 | 3592 | 408 | 1890 |
|
Chip 3
|
A
|
0 | 0 | 99.77 | 99.50 | 0.25 | 136.3 | 0 | 45.5 | 0/0 | 0 | 3717 | 339 | 866 |
|
Chip 4
|
A
|
1 | 0 | 99.81 | 99.41 | 0.25 | 138.9 | 0 | 46.7 | 0/0 | 0 | 3675 | 355 | 1074 |
|
Chip 5
|
A
|
0 | 0 | 99.78 | 99.47 | 0.3 | 182.2 | 0 | 60.5 | 0/0 | 0 | 3636 | 398 | 1736 |
|
Chip 6
|
A
|
0 | 0 | 99.84 | 99.54 | 0.18 | 138.1 | 0 | 45.3 | 0/0 | 0 | 3756 | 345 | 938 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.61 | 0.23 | 149.9 | 0 | 49.5 | 0/0 | 0 | 3654 | 382 | 1544 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.31 | 0.35 | 166.1 | 0 | 54.8 | 0/0 | 0 | 3680 | 366 | 1308 |
|
Chip 9
|
A
|
0 | 0 | 99.80 | 99.36 | 0.36 | 165.4 | 0 | 54.8 | 0/0 | 0 | 3655 | 372 | 1372 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.58 | 0.25 | 190.8 | 0 | 62.5 | 0/0 | 0 | 3651 | 359 | 1209 |
|
Chip 11
|
A
|
0 | 0 | 99.79 | 99.52 | 0.21 | 149.4 | 0 | 49.8 | 0/0 | 0 | 3693 | 351 | 1046 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.67 | 0.2 | 137.1 | 0 | 45.5 | 0/0 | 0 | 3740 | 334 | 821 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.56 | 0.28 | 248.6 | 0 | 80.8 | 0/0 | 0 | 3582 | 401 | 1807 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.60 | 0.34 | 235.5 | 0 | 77.8 | 0/0 | 0 | 3629 | 388 | 1597 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.56 | 0.39 | 275.0 | 0 | 90.9 | 0/0 | 0 | 3590 | 401 | 1765 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-03 | |
| TestTime | Test Time | 15:45 | |
| TestDuration | Duration | 0:37:8 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 901 | |
| nWarnings | # Warnings | 256 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 256 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 86 | |
| message_readback_count | Readback start marker | 170 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
