Test Date: 2016-11-14 16:28
Analysis date: 2016-11-14 17:35
Analysis date: 2016-11-14 17:35
M1103 XRayHRQualification
Summary
| Module | Module | M1103 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 7/0/9 | |
| PixelDefects | Total Pixel Defects | 10390 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.53 | % |
| Noise | Mean Noise | 370 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
702 | 0 | 99.79 | 99.51 | 0.56 | 90.4 | 279.8 | 0 | 0/0 | 0 | 3687 | 396 | 1734 |
|
Chip 1
|
C
|
702 | 0 | 99.47 | 98.94 | 14.59 | 83.5 | 260.9 | 0 | 0/0 | 0 | 3669 | 387 | 1618 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.55 | 0.39 | 79.5 | 242.4 | 0 | 0/0 | 0 | 3551 | 419 | 2026 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.59 | 0.21 | 49.2 | 149.1 | 0 | 0/0 | 0 | 3687 | 352 | 1073 |
|
Chip 4
|
C
|
914 | 0 | 99.85 | 99.89 | 0.94 | 46.3 | 140.8 | 0 | 0/0 | 0 | 3665 | 372 | 1386 |
|
Chip 5
|
C
|
914 | 0 | 99.80 | 99.54 | 0.38 | 61.0 | 190.2 | 0 | 0/0 | 0 | 3622 | 393 | 1668 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.48 | 0.23 | 45.7 | 138.9 | 0 | 0/0 | 0 | 3711 | 367 | 1294 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.51 | 0.23 | 48.5 | 149.4 | 0 | 0/0 | 0 | 3643 | 385 | 1549 |
|
Chip 8
|
C
|
863 | 0 | 99.81 | 99.61 | 0.22 | 46.0 | 140.0 | 0 | 0/0 | 0 | 3673 | 404 | 1840 |
|
Chip 9
|
C
|
863 | 0 | 99.76 | 99.50 | 0.32 | 47.8 | 146.6 | 0 | 0/0 | 0 | 3678 | 380 | 1452 |
|
Chip 10
|
A
|
24 | 0 | 99.82 | 99.52 | 0.24 | 52.1 | 158.6 | 0 | 0/0 | 0 | 3675 | 334 | 787 |
|
Chip 11
|
C
|
3812 | 0 | 99.81 | 99.72 | 0.28 | 46.9 | 142.2 | 0 | 0/0 | 0 | -237950721236831 | 148 | 91 |
|
Chip 12
|
C
|
806 | 0 | 99.82 | 99.37 | 0.21 | 45.0 | 136.4 | 0 | 0/0 | 0 | 3511 | 367 | 1277 |
|
Chip 13
|
C
|
790 | 0 | 99.79 | 99.57 | 0.28 | 64.2 | 196.0 | 0 | 0/0 | 0 | 3584 | 410 | 1913 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.62 | 0.33 | 77.2 | 240.1 | 0 | 0/0 | 0 | 3558 | 423 | 2124 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 99.58 | 0.35 | 79.8 | 245.5 | 0 | 0/0 | 0 | 3690 | 381 | 1537 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 16:28 | |
| TestDuration | Duration | 0:59:10 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 889 | |
| nWarnings | # Warnings | 118 | |
| channel_0_count | Channel 0 | 6 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 67 | |
| channel_3_count | Channel 3 | 64 | |
| message_eventid_count | Event ID mismatch | 46 | |
| message_notokenpass_count | has NoTokenPass | 21 | |
| message_readback_count | Readback start marker | 79 |
v1.1.1-1-g54fa876 on branch master
