Test Date: 2016-11-03 16:24
Analysis date: 2016-11-03 17:12
Analysis date: 2016-11-03 17:12
M1104 XRayHRQualification
Summary
| Module | Module | M1104 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.81/99.53 | % |
| Noise | Mean Noise | 395 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.53 | 0.4 | 268.7 | 0 | 86.4 | 0/0 | 0 | 3465 | 434 | 2236 |
|
Chip 1
|
C
|
0 | 0 | 99.82 | 99.48 | 6.13 | 237.2 | 0 | 78.2 | 0/0 | 2 | 3600 | 411 | 1881 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.58 | 0.25 | 261.9 | 0 | 86.0 | 0/0 | 0 | 3431 | 407 | 1833 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.59 | 0.24 | 157.3 | 0 | 52.3 | 0/0 | 0 | 3690 | 359 | 1214 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.52 | 0.32 | 148.8 | 0 | 49.5 | 0/0 | 0 | 3608 | 390 | 1629 |
|
Chip 5
|
A
|
1 | 0 | 99.81 | 99.49 | 0.26 | 180.0 | 1 | 59.4 | 0/0 | 0 | 3595 | 417 | 2030 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.65 | 0.35 | 153.6 | 0 | 50.9 | 0/0 | 0 | 3642 | 378 | 1471 |
|
Chip 7
|
A
|
1 | 0 | 99.79 | 99.35 | 0.32 | 168.0 | 1 | 56.0 | 0/0 | 0 | 3551 | 410 | 1924 |
|
Chip 8
|
A
|
0 | 0 | 99.78 | 99.51 | 0.3 | 147.3 | 0 | 49.0 | 0/0 | 0 | 3634 | 393 | 1690 |
|
Chip 9
|
A
|
0 | 0 | 99.77 | 99.56 | 0.33 | 151.3 | 0 | 50.2 | 0/0 | 0 | 3624 | 398 | 1768 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.48 | 0.25 | 177.8 | 0 | 58.7 | 0/0 | 0 | 3606 | 398 | 1734 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.57 | 0.19 | 135.7 | 0 | 45.6 | 0/0 | 0 | 3631 | 377 | 1482 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.53 | 0.21 | 151.0 | 0 | 50.5 | 0/0 | 0 | 3649 | 386 | 1573 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.55 | 0.26 | 211.5 | 0 | 69.8 | 0/0 | 0 | 3609 | 390 | 1623 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.56 | 0.3 | 209.8 | 1 | 69.3 | 0/0 | 0 | 3658 | 367 | 1281 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.55 | 0.35 | 267.4 | 0 | 85.9 | 0/0 | 0 | 3118 | 409 | 1899 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-03 | |
| TestTime | Test Time | 16:24 | |
| TestDuration | Duration | 0:37:58 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
