M1109 XRayHRQualification
| Comment | Comment | comment.txt: Bad DC on C9 |
Summary
| Module | Module | M1109 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | C | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.51 | % |
| Noise | Mean Noise | 382 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.79 | 99.53 | 0.32 | 201.7 | 0 | 67.1 | 0/0 | 0 | 3633 | 396 | 1729 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.28 | 0.2 | 165.0 | 0 | 54.6 | 0/0 | 0 | 3747 | 320 | 594 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.60 | 0.23 | 224.1 | 0 | 74.7 | 0/0 | 0 | 3656 | 367 | 1307 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.58 | 0.21 | 172.9 | 0 | 57.1 | 0/0 | 0 | 3670 | 377 | 1452 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.51 | 0.22 | 159.9 | 0 | 53.8 | 0/0 | 0 | 3713 | 356 | 1129 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.50 | 0.24 | 239.7 | 0 | 80.2 | 0/0 | 0 | 3641 | 386 | 1535 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.54 | 0.31 | 282.7 | 0 | 93.2 | 0/0 | 0 | 3546 | 418 | 2030 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.59 | 0.48 | 274.5 | 0 | 90.2 | 0/0 | 0 | 3635 | 392 | 1668 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.53 | 0.39 | 272.2 | 0 | 89.4 | 0/0 | 0 | 3611 | 416 | 1996 |
|
Chip 9
|
A
|
0 | 0 | 99.78 | 99.31 | 17.4 | 251.3 | 0 | 84.5 | 0/0 | 0 | 3634 | 386 | 1543 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.50 | 0.33 | 262.2 | 0 | 86.6 | 0/0 | 0 | 3582 | 411 | 1933 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.51 | 0.25 | 172.0 | 0 | 56.7 | 0/0 | 0 | 3623 | 397 | 1737 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.44 | 0.23 | 155.6 | 0 | 51.4 | 0/0 | 0 | 3667 | 370 | 1310 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.59 | 0.29 | 224.1 | 0 | 72.8 | 0/0 | 0 | 3627 | 382 | 1519 |
|
Chip 14
|
A
|
0 | 0 | 99.78 | 99.54 | 0.28 | 206.7 | 0 | 68.5 | 0/0 | 0 | 3674 | 384 | 1559 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.54 | 0.28 | 196.6 | 0 | 64.5 | 0/0 | 0 | 3684 | 356 | 1128 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-04 | |
| TestTime | Test Time | 14:01 | |
| TestDuration | Duration | 0:37:4 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 32 | |
| nWarnings | # Warnings | 6 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 4 |
