Test Date: 2016-11-07 10:55
Analysis date: 2016-11-07 11:41
Analysis date: 2016-11-07 11:41
M1120 XRayHRQualification
Summary
| Module | Module | M1120 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 68 | |
| BumpBondingDefects | Bump Bonding Defects | 64 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.56 | % |
| Noise | Mean Noise | 404 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.54 | 0.37 | 214.5 | 0 | 70.8 | 0/0 | 0 | 3588 | 400 | 1814 |
|
Chip 1
|
A
|
0 | 0 | 99.79 | 99.60 | 0.35 | 202.3 | 0 | 68.7 | 0/0 | 0 | 3580 | 389 | 1588 |
|
Chip 2
|
A
|
1 | 0 | 99.79 | 99.48 | 0.49 | 237.4 | 1 | 80.0 | 0/0 | 0 | 3571 | 400 | 1760 |
|
Chip 3
|
A
|
1 | 0 | 99.80 | 99.57 | 0.24 | 176.8 | 0 | 59.8 | 0/0 | 0 | 3587 | 385 | 1582 |
|
Chip 4
|
A
|
1 | 0 | 99.78 | 99.51 | 0.3 | 181.5 | 1 | 61.4 | 0/0 | 0 | 3517 | 435 | 2229 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.51 | 0.52 | 256.7 | 0 | 83.7 | 0/0 | 0 | 3415 | 440 | 2321 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.59 | 0.65 | 231.4 | 0 | 77.3 | 0/0 | 0 | 3650 | 384 | 1555 |
|
Chip 7
|
A
|
1 | 0 | 99.80 | 99.70 | 0.65 | 243.0 | 1 | 81.9 | 0/0 | 0 | 3590 | 396 | 1691 |
|
Chip 8
|
A
|
1 | 0 | 99.82 | 99.55 | 0.43 | 251.4 | 0 | 84.2 | 0/0 | 0 | 3671 | 372 | 1373 |
|
Chip 9
|
A
|
11 | 0 | 99.82 | 99.52 | 0.37 | 265.7 | 11 | 87.5 | 0/0 | 0 | 3519 | 416 | 1992 |
|
Chip 10
|
A
|
1 | 0 | 99.80 | 99.53 | 0.32 | 222.7 | 0 | 73.8 | 0/0 | 0 | 3648 | 393 | 1722 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.60 | 0.24 | 162.8 | 0 | 54.5 | 0/0 | 0 | 3594 | 395 | 1690 |
|
Chip 12
|
A
|
0 | 0 | 99.78 | 99.51 | 0.3 | 200.9 | 1 | 67.2 | 0/0 | 0 | 3455 | 436 | 2277 |
|
Chip 13
|
A
|
3 | 0 | 99.79 | 99.57 | 0.33 | 234.5 | 3 | 77.7 | 0/0 | 0 | 3585 | 401 | 1793 |
|
Chip 14
|
A
|
18 | 0 | 99.81 | 99.58 | 0.39 | 211.0 | 20 | 70.2 | 0/0 | 0 | 3560 | 416 | 1983 |
|
Chip 15
|
A
|
30 | 0 | 99.81 | 99.53 | 0.34 | 209.6 | 32 | 69.9 | 0/0 | 0 | 3565 | 398 | 1760 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-07 | |
| TestTime | Test Time | 10:55 | |
| TestDuration | Duration | 0:37:6 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 92 | |
| nWarnings | # Warnings | 15 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 5 | |
| message_readback_count | Readback start marker | 10 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
